    TICO-RAW is the new RAW

    TICO-RAW delivers the most beautiful pixels and most perfect colors, with the most brillant brights and the deepest darks ...with the world's best efficiency.

    Designed by intoPIX, it unleashes image sensor and traditional RAW data-flows thanks to an innovative processing and coding. The full power of the image sensor is preserved while reducing the bandwidth and storage needs. It offers high image quality and the capability to manage high resolution, high frame rate and high dynamic range workflows.

    TICO-RAW is the world’s first RAW codec that can offer compression efficiency with such low complexity on Bayer or Bayer-like Color Filter Arrays (CFA) patterns.
    High quality RAW
     ​Perfect for human vision - Perfect for machine vision

    Microsecond latency

    Traitement par ligne

    Qualité d'image RAW parfaite

    Size reduction down to 1 bpp

    Qualité sans perte

    Faible puissance et faible complexité

    Extremely low resource, low memory

    (pas d'utilisation de DRAM externe)

    Extremely Fast

    Toute résolution

    From 1 to 160 megapixels

    Up to 16bit RAW, HDR support

    Includes embedded proxy view

    Ready for your application

    Production Live sur IP

    Streaming from camera to remote CCU


    Cameras & DSLR

    Photography, Digital Camera, Movie Camera

     Camera modules

    Appareils mobiles

    Connectivité et interfaces


    GIS & Space

    The only way to get smaller raw file


    Automobile

    ADAS

    Réseau de véhicules

    Industrial

    Vision, Microscopy, Medical; VR/AR glasses

    Gain in Efficiency, improve your imaging workflows

    • Reduce bandwidth and power consumption to process more pixels from the sensor.
    • Handle higher resolution, high frame rate and high dynamic range easily : to capture  to record, to transmit, to edit, to analyze.
    • Reduce the bandwidth of memory during the ISP process and RAW data analysis.
    • Get the lowest latency ("pixel-line")  to transmit RAW data over your network, infrastructures, interfaces.
    • Efficiently decrease the stored RAW image data on the storage media (TICO-RAW is the new RAW at the size of a regular JPEG file).
    • Increase the editing, rendering, analytics speed and while retaining the sensor data needed for a complete control of the RAW processing pipeline.

    Image Sensors

    Camera Module

    Processors

    Network

    Processing & Storage

    Free up storage space and bandwidth needs
    ​From 2:1 to up to 16:1 with no compromise

    See how TICO RAW can help you to get smaller RAW storage or longer recording time

    See how TICO RAW can help you to transmit RAW at the speed of light over limited bandwidth.

      CONNECTIVITY DATA RATE REDUCTION
      DATA STORAGE REDUCTION
      CONNECTIVITY DATA RATE REDUCTION
      TICO-RAW @ 60fps@ 2 BPP @ 1 BPP
      Mbit/sMbit/s
       1920 x 1080250 Mbps125 Mbps
      4096 x 21601 Gbps500 Mbps
      7680 x 43204 Gbps2 Gbps

      Compression ratio according to the RAW bit depth :

      RAW  BIT DEPTH2 BBP  1 BPP
      105:110:1
      126:112:1
      147:114:1
      168:116:1
      DATA STORAGE REDUCTION
       TICO RAW 12bit @ 60 fps~ 2:1 (MLS) on 1TB SSD6:1 (2 BPP) on 1TB SSD12:1 (1 BPP) on 1TB SSD
       1920 x 1080 177 min533 min1066 min
      4096 x 216044 min133 min266 min
      7680 x 4320
      11 min27 min54 min

       Technical Specifications

      IMAGEFormat couleur
       CFA RAW Bayer (RGGB, RCCB, ...)
      (optional monochrome and 4:2:2 mode)
      Profondeur de bits 8 / 10 / 12 / 16 bits par composante
       Résolution Any up to 160 Mpixels (> 40.000x40.000 pixels)
       Fréquence d'images Any (depending on ASIC / FPGA IP-cores or Developer SDKs configuration)
      TRAITEMENTQualité Mathematically lossless / Near-lossless / visually lossless / lossy down to 1 bit per pixel (bpp)
      Contrôle du débit Constant bitrate (CBR) operation (or capped VBR), adjustable from ~2:1 down to 20:1  (0,5bpp)
      Latence (Sous-) intra-image: jusqu'à 0,1 milliseconde
      Option proxy  Downscaler in decoder for fast analysis, raw proxy viewing and editing

      Commencez votre évaluation et vos implémentations

      Evaluation versions, Full range of IP-cores for FPGA or ASIC, x86-64 or GPU SDKs are available today.
      It is possible to provide custom versions to address very specific needs.

      Contactez-nous pour plus d'informations
      ?
      Verification code

      Available for Hardware and Software

      GO TO PAGE

      Coeurs IP

      - Small footprint / low memory

      - Low power (no external DDR)

      - Various encoder & decoder versions


      Plate-formes :

      - FPGA Xilinx & Intel (toutes les familles)

      - ASIC tel que TSMC 12, 16, 28, 40nm

      SDK

      - Highly parallelized
      - Low latency
      - Real-time or faster than real-time

      Plate-formes :
      - GPU: Nvidia
      - CPU: x86-64 Intel / AMD
      - More on request
      GO TO PAGE
